In stock
SKU
L020496
Click & Collect
£3.38
Inc VAT
- Protects electrical installations against overloads and short circuits
- Compatible with an NM and NMX Wylex consumer unit
- This Wylex 50A MCB has a 6kA breaking capacity
- Single pole type B MCB
Product Information
The Wylex NHXLB50 is suitable for installation in Wylex NM and NMX consumer units. This MCB has a rated current of 50A and a breaking capacity of 6kA. The NHXLB50 protects electrical installations from damage caused by short circuits and overloads.
Key Features
- Type B curve, trips when the circuit is three to five times the recommended limit for the circuit
- In accordance with 18th IEE Edition Wiring Regulations, when installed correctly
- DIN rail mounted, featuring a convenient quick-release DIN clip
- Ideal for installation with NM and NMX consumer units
- Provides overload and short circuit protection
- Tunnel-type touch-proof captive terminals
- Has a no-miss busbar connection
- Generous terminal capacity
- Single pole MCB
Technical Information
- Connectable Conductor Cross Section Multi-Wired: 0.75-25 mm²
- Ambient Operating Temperature: -5 To +40 Degrees Celsius
- Installation: 35mm DIN Rail Mounted
- Impulse Withstand Voltage: 4kV
- Width Excluding Switch: 50mm
- Width Including Switch: 73mm
- Energy Limiting Class: 3
- Breaking Capacity: 6kA
- Standard: EN 60898-1
- Voltage Rating: 230V
- Thickness: 17.5mm
- Number Of Poles: 1
- Voltage Type: AC
- Frequency: 50Hz
- Brand: FuseBox
- Amperage: 50A
- IP Rating: IP20
- Height: 90mm
Wylex Data Sheet (PDF)
Product Specifications
| Brand: | Wylex |
|---|---|
| MPN: | NHXB50 |
| Amperage: | 50A |
