SKU
L073198
Click & Collect
Quantity Discount
- Up to 9£11.88Inc VAT
- 10 & Over £10.69 Inc VAT
£11.88
Inc VAT
- The GreenBrook Henley Connector Block CB35D is 100A rated
- Heavy duty connection block for use at meter and mains position
- 35mm² cable terminal capacity
- 103.7 x 68.6 x 68mm
- Double pole
- 2 x 5 ways
Product Information
This GreenBrook 100A 2 x 5 Way 35mm² Connector Block CB35D is a heavy duty henley block for use at meter and mains position and is made of durable ABS plastic.
Key Features
- Constructed from high-quality ABS plastic
- Designed with easy knockout entries
- The lids can be sealed for security
- Double pole connector block
- Supplied with steel screws
- Has 2 x 5 ways
Technical Information
- Operating Temperature Range: -10°C - +40°C
- Torque Setting: 3.5Nm, Screw Size M8
- Cable Terminal Capacity: 35mm²
- Size: 103.7 x 68.6 x 68mm
- Number Of Poles: Double
- Number Of Ways: 2 x 5
- Brand: GreenBrook
- Rating: 100A
- Colour: Black
Approvals
- BS EN 60998-2-1
- BS EN 60998-1
Guarantee
- 1-year manufacturer's guarantee
Product Data Sheet (PDF)
Product Specifications
| Brand: | GreenBrook |
|---|---|
| MPN: | CB35D |
| Amperage: | 100A |
| Colour: | Black |
| Finish: | Black Plastic |
| Ip Rating: | Non IP Rated |
| Material: | Plastic |
| Size: | 35mm |
| Wiring Accessories Type: | Henley Block |
| Shipping Weight Kg: | 0.188 kg |
| Shipping Dimension 1: | 104 mm |
| Shipping Dimension 2: | 69 mm |
| Shipping Dimension 3: | 68 mm |
