- This Ermetika FD30 pocket door system creates the framework for installing a door that opens by sliding into the wall
- Includes the metal pocket door framework, self-closing mechanism, floor guide, softwood doorjambs, intumescent strips, fixings and instructions
- FD30 rating helps contain flames for up to 30 minutes when used with fire doors
- Compatible with 686 x 1981mm doors that are 42-45mm thick
- For installation in 100mm finished plasterboard walls
Please note that the door is not included
Product Information
This Ermetika EvoKit Single FD30 Pocket Door System 686 x 1981mm provides the framework for installing an internal sliding door. It has an FD30 rating, making it suitable for use with fire-rated doors, to slow the spread of flames for up to 30 minutes. The system is for 686 x 1981mm doors with a thickness between 42-45mm.
Please note that this kit does NOT contain a door. Fire doors will need to be purchased separately.
Key Features
- The self-closing mechanism automatically pulls the door shut after it is mostly closed, enhancing privacy and fire resistance
- Comes with softwood doorjambs to neatly finish the door opening and support hardware like latches
- Creates the framework for a door that opens by sliding into the wall, offering a space-saving solution
- For use with FD30 fire doors to slow the spread of flames for 30 minutes
- Quick and easy to install with a snap-fit assembly system
- Strong metal structure with horizontal reinforcements
- The system contains an aluminium extractable rail
- Suitable for use with plasterboard walls
- 'Easy roll' track offers silent operation
- Fully tested for long-term durability
Technical Information
- Compatible Finished Wall Thickness: 100mm
- Compatible Door Panel Size: 686 x 1981mm
- Passage Opening Size: 635 x 1960mm
- Compatible Door Thickness: 42-45mm
- Overall Dimensions: 1470 x 2062mm
- Wall Cavity Width: 54mm
- Frame Thickness: 75mm
Product Includes
- Self-closing mechanism components
- A self-centering floor guide
- Metal pocket door frame
- Installation Instructions
- Softwood doorjambs
- Intumescent strips
- Fixings
Approvals
- BS EN 1634-1:2009
- EN 13501-2:2016
Product Data Sheet (PDF)
Product Specifications
| Brand: | Ermetika |
|---|---|
| MPN: | EEFSCUK3 |
| Fire Rating: | FD30 |
| Height: | 1981mm |
| Product Type: | System |
| Width: | 686mm |
| Shipping Weight Kg: | 25 kg |
| Shipping Dimension 1: | 100 mm |
| Shipping Dimension 2: | 655 mm |
| Shipping Dimension 3: | 1960 mm |
