End Feed 90° Street Elbow 22mm

SKU
P000481
Quantity Discount

End Feed 90° Street Elbow 22mm

SKU
P000481
Click & Collect

Quantity Discount

  • Up to 9£0.91Inc VAT
  • 10 & Over £0.82 Inc VAT
£0.91 Inc VAT
  • The Lawton Tube End Feed 90° Street Elbow connects two 22mm pipes at a 90-degree angle
  • Should be fitted using tin solder
  • Space-saving street fitting design
  • 22mm diameter

Product Information

This Lawton Tube End Feed 90° Street Elbow 22mm connects two 22mm pipes at a 90-degree angle. One end of the fitting is for end feed soldering, with the other fitting into another plumbing part. This end feed elbow should be fitted using tin solder.

Key Features

  • Street connectors have a space-saving design with one end fitting inside a pipe and another that connects to fittings/valves
  • Cost-effective way of joining copper tubes
  • Provides a waterproof connection
  • Strong, one-piece construction
  • Suitable for copper pipes

Technical Information

  • Working Pressure At 110°C: 16 bar
  • Working Pressure At -40°C: 25 bar
  • Working Pressure At 30°C: 25 bar
  • Working Pressure At 65°C: 25 bar
  • Brand: Lawton Tube
  • Size: 22mm

Approvals

  • WRAS Approved
  • BS EN 1057
  • EN 1254-1

Product Specifications

Technical Specification
Brand: Lawton Tube
MPN: EFELS022
Diameter: 22mm
Plumb Type: Elbows
Shipping Weight Kg: 0.041 kg
Shipping Dimension 1: 60 mm
Shipping Dimension 2: 45 mm
Shipping Dimension 3: 22 mm
