SKU
L068574
Click & Collect
£184.67
Inc VAT
- This 25mm² Double Insulated Flexi Meter Tail has a brown PVC outer sheath and a brown insulated core
- Suitable for small power and lighting applications
- Stranded annealed copper conductor
- 19 strands per core
- 6181Y 50m drum
Product Information
This 25mm² Double Insulated Flexi Meter Tail Brown/Brown is for small power and lighting applications in both domestic and light commercial areas. The 6181Y comes in a 50m drum.
Key Features
- Ideal for small power and lighting installations
- Class 2 stranded annealed copper conductor
- Brown PVC outer sheath colour
- Brown PVC insulation
- 19 strands per core
Technical Information
- Maximum Conductor DC Resistance at 20°C: 0.727 ohm/km
- Maximum Operating Temperature: +70°C
- Voltage Rating: 300/500V
- Air Current Carrying Capacity: 108A
- Short Circuit Temperature: 160°C
- Minimum Installation Radius: 8D
- Oversheath Thickness: 1.1mm
- Insulation Thickness: 1.2mm
- Stranding: 19 / 1.26mm²
- Conductor Size: 25mm²
- Colour: Brown, Brown
- Conductor Class: 2
- Length: 50m
- Cores: 1
Matching Products
Approvals
- BS 6004:2012
- BS EN 60228
- BS EN 50363-3
- BS 7655-4.2
Product Disclaimer
- Please note that the cable size in the product name refers to the cross-sectional area of the conductors. The overall cable diameter, including insulation and sheath, will be larger than the stated conductor size.
Product Specifications
| Brand: | Builder Depot |
|---|---|
| MPN: | 25DIBRBRFL5 |
| Cable Length: | 50m Reel |
| Cable Type: | Meter Tail |
| Colour: | Brown |
| Cores: | 1 Core |
| Size: | 25mm |
| Shipping Weight Kg: | 16.35 kg |
| Shipping Dimension 1: | 250 mm |
| Shipping Dimension 2: | 250 mm |
| Shipping Dimension 3: | 240 mm |
